The series complies with the relevant conditions of GB6245-2006 & GB7956-2014, and have passed the national testing center certificates and obtained 3C certificates.These vehicle fire pumps can be used in special occasions such as high altitude and low temperature. They are the preferred configuration for China VI vehicles.
Without changing the external dimensions, they can achieve rated parameters of 100 L/s, 110L/s and 120L/s. They comply with the relevant conditions of GB6245-2006 & GB7956-2014, have passed the national testing center certificates and obtained 3C certificates.The main performance and structure of this series can replace similar imported fire pumps and can be used in special occasions such as high altitude and low temperature. They are the preferred configuration for China VI vehicles.
Structural Features and Advantages
1. PTO type power take-off connection.
2. Wide flow ranges from 100, 110, 120L/s @ 1.0MPa.
3. The Single-stage pump's body material is aluminum alloy or copper.
4. Gearbox housing is high-strength aluminum alloy.
5. Impeller material is tin bronze, corrosion-resistant and wear-resistant, ensuring reliable operation in harsh environments.
6. Impeller shaft material is high-strength stainless steel.
7. Adopt maintenance-free mechanical seal.
8. Multiple speed ratio options: 45/41, 59/27, 57/29, 49/37, 53/33.
9. Pump Head Dimensions: 625*575*630mm(L*W*H),weight: 165Kg.
Technical Parameters At 3m Suction Lift
|
Item |
Operation I |
Operation II |
|||||||
|
Model |
Flow L/s |
Discharge Pressure MPa |
Speed rpm |
Power Kw |
Flow L/s |
Discharge pressure MPa |
Speed rpm |
Power Kw |
|
|
CB10/100-TB |
100 |
1 |
2750 |
146 |
70 |
1.3 |
2890 |
141 |
|
|
CB10/110-TB |
110 |
1 |
2840 |
165 |
77 |
1.3 |
2930 |
152 |
|
|
CB10/120-TB |
120 |
1 |
2900 |
181 |
84 |
1.3 |
2950 |
161 |
|
|
CB10/120-TB-210 |
120 |
1 |
2680 |
194 |
84 |
1.3 |
2800 |
203 |
|
Optional Accessories:
1. DC24V Electric Vane Vacuum Pump Priming System;
2.Discharge valves: Handwheel Ball Valve, Handwheel Check Valve, Manual Ball Valve.
3. Customized suction and discharge Pipelines.
4. Full Flow Class B Foam Proportioning System.
5. Fire Pump Control System.
6. On-board Mounting Bracket.
